DH4C Installation Guide
p. 6
DH4C Installation
DH4C Installation
Installation Requirements
Before you begin, keep in mind that it is your responsibility to avoid damaging safety or electrical systems. If you are not
condent in your ability to perform the procedures in this guide, please contact Safe Fleet for assistance.
The following table outlines the physical and environmental requirements for installing a DH4C DVR:
VENTILATION Install the DVR away from any sort of heat outlet, heater, or AC blower. Do not operate the DVR
in a closed -in area, or restrict ventilation in any way. The DVR requires air circulation to maintain
optimum operation temperature and provide best performance. Do not expose the DVR to
moisture!
SURFACE Do not mount the DVR to a plastic panel or other surface that is subject to constant vibration.
ORIENTATION Install the DVR horizontally, vertically, or upside-down.
CLEARANCE Allow sucient clearance of at least 6 inches in front of the DVR and 2 inches to each side for
removal of the security front cover and easy access to the USB ports. Allow sucient clearance
behind the DVR for camera cables, mounting cables, Ethernet cables, and power cables.
MOUNTING CABLES The rear-most surface of the cable cover will be about 3 inches from the back of the DVR to
allow camera cables to bend over each other.
ETHERNET CABLES Avoid right angle bends in the Ethernet cables.
POWER CABLES Provide enough slack on the power cable to prevent any force from being exerted on the
connectors. A single 4-inch diameter loop is sucient.
WARNING
It is your responsibility to avoid damaging safety or electrical systems. Ensure you read and understand the DH4C DVR
Installation Requirements.
If you are not condent in your ability to perform the procedures in this tutorial, please contact Safe Fleet.
