SAJ Suntrio-TL Series User Manual

User Manual
User Manual
User Manual
7
Type Suntrio-TL12K Suntrio-TL15K Suntrio-TL17K Suntrio-TL20K
Input (DC)
Max. DC Power [W] 12500 15600 17700 20600
Max. DC Voltage [V] 1000V
MPPT Voltage Range [V] 240~800 240~800 240~800 240~800
Nominal DC Voltage 600
Start DC Voltage[V] 300
Minimum DC Voltage[V] 200
Max. DC input Current PV1 / PV2 [A] 18/18 22/22 22/22 22/22
Number of MPPT 2
String(s) per MPPT 2 3
DC Switch Optional
Output (AC)
Rated AC Power [W](@230V,50Hz) 12000 15000 17000 20000
Max. AC Apparent Power [VA] 12000 15000 17000 20000
Rated AC Current[A] 17.4 21.7 24.6 29.0
Max. AC Current [A] 19.0 25.0 27.0 29.0
Nominal AC voltage/ range 3/N/PE,220/380V,230/400V,240/415V;180V-280V/312V-485V
Grid frequency/ range 50Hz,60Hz /44Hz-55Hz,54-65Hz
Total Harmonic Distortion [THDi] < 3%(at nominal power)
Power factor, adjustable 0.9 leading~0.9 lagging
Feed-in Phase / Connection Phase 3 / 3
Efciency
Max. Efciency 98.1% 98.1% 98.1% 98.1%
Euro Efciency (at 600V
dc
) 97.4% 97.5% 97.5% 97.5%
MPPT Accuracy >99.5%
Protection
Internal Overvoltage Protection Integrated
DC Insulation Monitoring Integrated
DCI Monitoring Integrated
GFCI Monitoring Integrated
Grid Monitoring Integrated
AC Short Circuit Current Protection Integrated
Thermal Protection Integrated
Anti-island protection monitoring AFD
Interface
DC Connection H4/MC4
LCD Display Graphic LCD Display, Backlight, Inverter Parameter and Data Display
Display Language Multi Language
Datalogger & Communication RS485,Ethernet(Webserver embedded), WiFi(Optional),
Device Data
Topology Transformerless
Consumption at Night [W] <1
Consumption at Standby [W] <12
Operating Temperature Range :-20°C to +60°C(45°C to 60°C with derating)
Cooling Method Fans
Ambient Humidity 0% to 95% Non-condensing
Site Altitude Up to 2000m without power derating
Noise Emission (dBA) <45dB(with fan<50dB)
IP Protection IP65
Dimensions (WxHxD) [mm] 480×680 ×200
Weight [kg] 42
Standard Warranty (Year) 5 / 10 (Optional)
Certicates
AS4777, AS 3100, VDE0126-1-1/A1, G59-2, C10/11, UTE C15-712-1, TF3.2.1, EN
50438, IEC 62116, IEC 61727, IEC61000-6-2/3, IEC 62109-1/2
