SAJ Suntrio-TL Series - Technical Data

User Manual
6
User Manual
3.3 Technical Data
Type Suntrio-TL6K Suntrio-TL8K Suntrio-TL10K
Input (DC)
Max. DC Power [W] 6300 8200 10400
Max. DC Voltage [V] 1000V
MPPT Voltage Range [V] 240~800 240~800 240~800
Nominal DC Voltage 600
Start Voltage[V] 300
Min. DC Voltage[V] 200
Max. DC input Current PV1 / PV2 [A] 16 / 16
Number of MPPT 2
String(s) per MPPT 2
DC Switch Optional
Output (AC)
Rated AC Power [W](@230V,50Hz) 6000 8000 10000
Max. AC Apparent Power [VA] 6000 8000 10000
Rated AC Current[A] 8.7 11.6 14.5
Max. AC Current [A] 9.7 12.9 15.8
Nominal AC voltage/ range 3/N/PE, 220/380V,230/400V,240/415V;180V-280V/312V-485V
Grid frequency/ range 50Hz,60Hz /44Hz-55Hz,54-65Hz
Total Harmonic Distortion (THDi) < 3%(at nominal power)
Power factor, adjustable 0.9 leading~0.9 lagging
Feed-in Phase / Connection Phase 3 / 3
Efciency
Max. Efciency 97.9% 97.9% 98.0%
Euro Efciency (at 600V
dc
) 97.3% 97.3% 97.5%
MPPT Accuracy >99.5%
Protection
Internal Overvoltage Protection Integrated
DC Insulation Monitoring Integrated
DCI Monitoring Integrated
GFCI Monitoring Integrated
Grid Monitoring Integrated
AC Short Circuit Current Protection Integrated
Thermal Protection Integrated
Anti-island protection monitoring AFD
Interface
DC Connection H4/MC4
LCD Display Graphic LCD Display, Backlight, Inverter Parameter and Data Display
Display Language Multi Language
Datalogger & Communication RS485,Ethernet(Webserver embedded), WiFi(Optional),
Device Data
Topology Transformerless
Consumption at Night [W] <1
Consumption at Standby [W] <12
Operating Temperature Range :-20°C to +60°C(45°C to 60°C with derating)
Cooling Method Fans
Ambient Humidity 0% to 95% Non-condensing
Altitude Up to 2000m without power derating
Noise [dBA] <40dB
Ingress Protection IP65
Dimensions [WxHxD] [mm] 480×680 ×200
Weight [kg] 35
Standard Warranty [Year] 5 / 10 (Optional)
Certicates
AS4777, AS 3100, VDE0126-1-1/A1, G83-2,G59-2, C10/11, UTE C15-712-1,
TF3.2.1, EN 50438, IEC 62116, IEC 61727, IEC61000-6-2/3, IEC 62109-1/2
