4.Installation Instructions
4.1Unpacking
Check the delivery for completeness and for any visible external damage. Contact your specialist
dealer if anything is damaged or missing.
A B C D E
F G H I
Figure 4.1 Inverter and Accessories
Object Quantity Description
A 1 SAJ Suntrio solar inverter
B 1 Rear panel
C
4 sets for Suntrio-TL6K/8K/10K/12K
6 sets for Suntrio-TL15K/17K/20K
DC connector
D 7 M6×50 Expansion screw
E 7 Expansion tube
F 1 RS485 connector(if attached)
G 4 M4×12 Cylinder head screw and Lock washer
H 1 User manual, including installation guide
I 1 Warranty card
Table 4.1 Detail Information of Inverter and Accessories
