15
A B C D E
F G
Figure 5.2 Connection Area Overview of Suntrio-TL15K/17K/20K
Object Description
A DC input terminals (PV1 and PV2)
B DC switch (optional)
C EXT port
D Ethernet RJ45 interface
E AC cover terminal
F RS485 interface
G Grounding terminal
Table 5.1 Description of Connection Area
