RS485-L Cable
RS485-L cable is used to connect Inverter and SAJ Logger when inverters are monitored via
RS485. One end of the cable uses 3Pin Connector, and the other end uses RJ45 Plug. Connection
is shown in Table 5.5 as below:
Wire Connector No. RJ45 plug's Pin NO
Blue & White 1 5
Blue 2 4
Table 5.5 RS485-L Cable Assembly Order
RJ45 Cable
RJ45 cable is the standard cable for Ethernet communication. Users can buy this cable in stores,
or can assemble RJ45 cable as below:
Each end of the cable must be connected to RJ45 Plug according to Table 5.6. Make sure they
are xed well.
RJ45 plug's Pin NO
One RJ45 plug's
Wire color
One RJ45 plug's
Wire color
1 White & Green White & Orange
2 Green Orange
3 White & Orange White & Green
4 Blue Blue
5 White & Blue White & Blue
6 Orange Green
7 White & Brown White & Brown
8 Brown Brown
Table 5.6 RJ45 Cable Assembly Order
