3 Manual operation
Switch to manual mode to configure all outputs (see wiring diagram in section 11).
The manual operation for the different control circuits is set at the rotary switches:
Manual operation Rotary switch Position
Heating circuit 1* Top
Heating circuit 2* Middle
DHW heating/heating circuit 3* Bottom
* Refer to page 161 for assignment
Proceed as follows:
Turn appropriate rotary switch to position “Manual operation“.
q
Select:
POS_ : Correction value in percent
UP_: Activation of the circulation pump
SLP: Activation of the storage tank charging pump
Confirm selection.
Display blinks.
q
Edit the correction value or activate/deactivate the circulation pump, etc.
Confirm edited settings.
The modified values remain active as long as the controller is in manual mode.
Return the rotary switch to the required operating mode (left side).
Manual operation of the selected control circuit is deactivated by switching to any other
operating mode.
Note: Simply setting the rotary switch to position “Manual operation“ has no influence on
the outputs. You have to actually enter a correction value or activate/deactivate the pumps to
configure the outputs.
In manual mode, frost protection (–> section 7.2) is not activated.
28 EB 5579 EN
