9.5 Memory module
The use of a memory module (order no. 1400-9379) is particularly useful to transfer all data
from one TROVIS 5579 Controller to several other TROVIS 5579 Controllers. The memory
module is plugged into the RJ-45 jack integrated into the front panel. Once the module has
been connected, “79 SP“ is displayed. If the memory module already contains data from a
different TROVIS 5579 Controller, turn the rotary pushbutton until “SP 79" is displayed.
4
Pressing the rotary pushbutton to confirm “79 SP“ causes the controller settings to be
transferred to the memory module.
4
Pressing the rotary pushbutton to confirm “SP 79“ causes the saved controller settings to
be transferred from the memory module to the controller.
During the data transfer, the bars on the display indicate the progress. When the transfer
was successful, “I.O.“ is displayed. After that, the connection between controller and mem-
ory module can be terminated.
Using TROVIS-VIEW (order no. 6661-1013), it is possible to configure all controller settings
on a convenient user interface on the PC and to document these settings.
9.6 Data logging
The new hardware 5579-xxx3 automatically saves operating data, such as temperatures
measured by the sensors, control signals, switching states of the pump outputs etc., in an in-
tegrated historical data memory every minute. The memory can hold approximately two
weeks of data. The data logging module (order no. 1400-9378) can be used to copy the op-
erating data stored in the integrated memory every two minutes or to directly log the operat-
ing data every two minutes. After connecting the data logging module at the front RJ-45
jack, select
LOG
or
COPY
on the display to choose the logging or copying function of the
module. If no selection is made, data logging starts automatically after two minutes.
The controller starts to write over the oldest data as soon the memory of the data logging
module or integrated historical data memory is full. The current memory capacity of the data
logging module can be read in the extended operating level under
Info 2
as the second
value in the sequence (range of values: 0 to 6035). Directly after inserting the data logging
module, data can be first read after the first scanning cycle has been performed.
The Datalogging Viewer software allows the data to be viewed in graph format. The USB
converter 3 (order no. 1400-9377) is required to connect the data logging module to a com-
puter. The Datalogging Viewer software is supplied with the USB converter 3.
EB 5579 EN 127
Communication
