Samson TROVIS 5579 - Page 44

System Anl 5.0
Default settings
CO1 -> F02 - 1 (with AF1)*
CO1 -> F03 - 1 (with RüF1)
CO2 -> F01 - 0 (without RF2)
CO2 -> F02 - 0 (without AF2 for Rk2)*
CO2 -> F03 - 0 (without RüF2)
CO3 -> F01 - 0 (without RF3)
CO3 -> F02 - 0 (without AF2 for Rk3)*
CO3 -> F03 - 0 (without RüF3)
44 EB 5579 EN
Systems
UP1 UP1
BE
BA
AE
AA
AF1
RüF1
VF1
UP2 UP3
RK2/Y2RK1/Y1
RF2VF2
RüF2 RK3/Y3 RüF3
RF3
VF3
