Exploded Views and Parts List
5-40Samsung Electronics
■
Parts List
No. Code No. Description Specification SA/SNA
Q'TY
AVXWHH028E
✳
AVXWHH036E
✳
1 DB92-00633B ASS'Y PANEL FRONT ASS'Y 1 1
1-1 DB64-01210B PANEL FRONT HIPS 1 1
1-2 DB63-01103A FILTER-PRE PP 1 1
2 DB94-00629A ASS'Y TRAY DRAIN ASS'Y 1 1
2-1 DB63-01104A TRAY DRAIN ABS 1 1
2-2 DB61-02049A BLADE-H ABS 1 1
2-3 DB61-02053A BLADE-V PP 2 2
2-4 DB73-00234A RUBBER-CAP DRAIN CR 1 1
2-5 DB94-00062L ASS'Y DRAIN-HOSE ASS'Y 1 1
2-5-1 DB67-00510A DRAIN-CUFF ABS 1 1
2-6 DB95-20138A ASS'Y MOTOR-STEPPING 24BYJ48 1 1
3 DB93-02960A ASS'Y DISPLAY ASS'Y 1 1
3-1 DB61-02056A HOLDER DISPLAY HIPS 1 1
3-2 DB64-01211A WINDOW DISPLAY HIPS 1 1
3-3 DB93-02806A ASS'Y PCB DISPLAY ASS'Y 1 1
3-4 DB93-01369A ASS'Y MODULE PCB ASS'Y 1 1
4 DB63-01448A COVER TERMINAL HIPS V0 1 1
5 DB63-01107B COVER PCB-DVM HIPS 1 1
6 DB61-02050A HOLDER EVAP ABS 1 1
7 DB61-02052A HOLDER MOTOR PP 1 1
8 DB93-03659B ASS'Y CONTROL IN ASS'Y 1 1
9 DB96-05269D ASS'Y EVAP TOTAL ASS'Y - 1
DB96-05269C ASS'Y EVAP TOTAL ASS'Y 1 -
9-1 DB60-00198A SPACER-EVAP MID PVC 1 1
9-2 DB60-00203B SPACER-EVAP UP PVC 1 1
9-3 DB96-05313B ASS'Y EVAP FP1.3, H-FIN, 2x12 - 1
DB96-05313A ASS'Y EVAP FP1.5, H-FIN, 2x12 1 -
10 DB67-60030A SPRING-SENSOR STS 301 1 1
11 DB94-00674A ASS'Y BEARING-RUBBER ASS’Y, CR 45 1 1
12 DB94-00627A ASS'Y-CROSS FAN ø83 x 719 1 1
13 DB31-00270A MOTOR FAN-IN YDK-20S4D8C-1 1 1
14 DB94-00626D ASS'Y BACK BODY ASS'Y 1 1
14-1 DB61-02057A BODY BACK HIPS 1 1
14-2 DB61-02047A BUSH BODY LF HIPS 1 1
14-3 DB61-02048A BUSH BODY RH HIPS 1 1
14-4 DB63-01105A COVER-IONIZER HIPS 1 1
14-5 DB91-00287A ASS'Y ELECTRIC-IONIZER ASS'Y 1 1
14-6 DB93-01383G ASS'Y C/W ION ASS'Y 1 1
15 DB61-02051A HOLDER-PIPE HIPS 1 1
16 DB67-00508A CAP SCREW HIPS 3 3
SA
SNA
SA
SA
SNA
SA
SA
SA
SA
SNA
SA
SA
SNA
SNA
SNA
SA
SNA
SNA
SNA
SNA
SNA
SA
SA
SNA
SNA
SNA
SNA
SNA
SA
SA
SA
SA
SNA
SNA
SNA
SNA
SA
SNA
SNA
SNA
