Exploded Views and Parts List
Samsung Electronics5-41
■
Parts List(cont.)
No. Code No. Description Specification SA/SNA
Q'TY
17 DB70-00514A PLATE-HANGER SGCC-M, T0.8 1 1
18 DB70-00515A PLATE CONTACT SUS 304 1 1
19 DB70-00516A PLATE-CONTROL IN SGCC-M 1 1
20 DB93-03016R ASS'Y REMOCON ARH-1315 1 1
21 DB92-00643C ASS'Y GRILLE ASS'Y 1 1
22 DB90-01829J ASS'Y COVER DISPLAY ASS'Y 1 1
22-1 DB63-01108A COVER DISPLAY PC 1 1
22-2 DB64-01276A INLAY DISPLAY ACRYL 1 1
23 DB90-01920A ASS'Y COVER CONTROL ASS'Y 1 1
AVXWHH028E
✳
AVXWHH036E
✳
SA
SNA
SNA
SA
SA
SNA
SNA
SNA
SNA
To Next Page
