Samsung DVM Plus 2 Series User Manual

Exploded Views and Parts List
5-52Samsung Electronics
■
Parts List
No. Code No. Description Specification SA/SNA
Q'TY
1 DB90-01533B ASS'Y-CABINET TOP COVER ASS'Y
2 DB90-01588A ASS'Y CABINET BACK-LF ASS'Y
3 DB90-01535B ASS'Y-CABINET FRONT LF ASS'Y
4 DB90-01534B ASS'Y-CABINET FRONT RH ASS'Y
5 DB99-00538B ASS'Y-CABINET BASE PART ASS'Y
6 DB67-00438A FAN-PROPELLER PP
7 DB31-00240C MOTOR FAN OSME 924SRC
8 DB31-00240D MOTOR FAN OSME 914SRC
9 DB90-01532B ASS'Y-PARTITION ASS'Y
10 DB99-00704B VALVE SERVICE 5/8"
11 DB99-00705B VALVE SERVICE 3/8"
12 DB96-05625A ASS'Y COND-UNIT ASS'Y
13 DB99-00748A ASS'Y VALVE 4 way ASS'Y
13-1 DB95-00808A
ASS'Y SWITCH PRESSURE HIGH ASS'Y
13-2 DB95-00809A
ASS'Y SWITCH PRESSURE LOW ASS'Y
14 DB95-00408H ASS'Y DSC COMP ZPD61KCE-PFZ
DB95-00637B ASS'Y DSC COMP ZPD67KCE-PFZ
15 DB99-00746A ASS'Y VALVE-EXPANSION ASS'Y
DB99-00746B ASS'Y VALVE-EXPANSION ASS'Y
16 DB62-03382A INSULATION-FELT POLYESTER
17 DB62-03381A INSULATION-FELT POLYESTER
18 DB32-00137A THERMISTOR-OUT -20˚C~+100˚C,220V,103AT
19 DB32-00139A THERMISTOR DISCHARGE 200Kohm,-,-20~+150
20 DB93-03836B ASS'Y CONTROL OUT ASS'Y
DB93-03836A ASS'Y CONTROL OUT ASS'Y
20-1 DB61-40291C WIRE HOLDER PP
20-2 DB61-02368A FUSE HOLDER ASS'Y
21 DB90-01539A ASS'Y BRACKET MOTOR ASS'Y
22 DB90-01589B ASS'Y CABINET BACK-RH ASS'Y
23 DB93-03828A ASS'Y MAIN PCB ASS'Y
DB93-03828B ASS'Y MAIN PCB ASS'Y
24 DB97-02613A ASS'Y BRACKET-VALVE ASS'Y
25 DB61-01857A BRACKET WIRE SECC-P,T1.0
26 DB64-01231A HANDEL SC-90073R
27 DB99-00618C ASS'Y LIQUID BYPASS V/V ASS'Y
28 DB99-00619B ASS'Y HOT GAS V/V ASS'Y
29 DB95-00564C ASS'Y HEATER COMP ASS'Y
30 DB99-00747A ASS'Y PWM VALVE ASS'Y
31 DB63-00691A GUARD FAN ASS'Y
32 DB96-04538B ASS'Y TUBE RECEIVER ASS'Y
33 DB96-05678A ASS'Y TUBE SUCTION ASS'Y
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
-
1
-
1
1
1
1
1
-
2
1
1
1
1
-
1
1
3
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
-
1
-
1
1
1
1
1
-
1
2
1
1
1
-
1
1
1
3
1
1
1
1
2
1
1
SA
SNA
SA
SA
SA
SA
SA
SA
SA
SNA
SNA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SNA
SA
SA
SNA
SNA
SA
SA
SA
SA
SA
SA
SA
SA
RVXMHF040E
✳
RVXMHF050E
✳
