Exploded Views and Parts List
Samsung Electronics5-53
■
Parts List
No. Code No. Description Specification SA/SNA
Q'TY
1 DB90-01533B ASS'Y-CABINET TOP COVER ASS'Y 1
2 DB90-01588A ASS'Y CABINET BACK-LF ASS'Y 1
3 DB90-01535B ASS'Y-CABINET FRONT LF ASS'Y 1
4 DB90-01534B ASS'Y-CABINET FRONT RH ASS'Y 1
5 DB99-00538B ASS'Y-CABINET BASE PART ASS'Y 1
6 DB67-00438A FAN-PROPELLER PP 1
7 DB31-00240C MOTOR FAN OSME 924SRC(S913) 1
8 DB31-00240D MOTOR FAN OSME 914SRC(S912) 1
9 DB90-01532B ASS'Y-PARTITION ASS'Y 1
10 DB99-00704B VALVE SERVICE 5/8" 1
DB99-00704A VALVE SERVICE 3/4" -
11 DB99-00705B VALVE SERVICE 3/8" 1
12 DB96-05625A ASS'Y COND-UNIT ASS'Y 1
13 DB99-00748A ASS'Y VALVE 4 way ASS'Y 1
DB99-00748B ASS'Y VALVE 4 way ASS'Y -
13-1 DB95-00808A
ASS'Y SWITCH PRESSURE HIGH
ASS'Y 1
13-2 DB95-00809A
ASS'Y SWITCH PRESSURE LOW
ASS'Y 1
14 DB59-00009B ASS'Y DSC COMP ZPD72KCE-TFD 1
DB95-00636B ASS'Y DSC COMP ZPD83KCE-TFD -
15 DB99-00746B ASS'Y VALVE-EXPANSION ASS'Y 1
DB99-00746C ASS'Y VALVE-EXPANSION ASS'Y -
16 DB62-03382A INSULATION-FELT POLYESTER 1
17 DB62-03381A INSULATION-FELT POLYESTER 1
18 DB32-00137A THERMISTOR-OUT -20˚C~+100˚C,220V,103AT 1
19 DB32-00139A THERMISTOR DISCHARGE 200Kohm,-,-20~+150 1
20 DB93-03836C ASS'Y CONTROL OUT ASS'Y 1
20-1 DB61-40291C WIRE HOLDER PP 2
20-2 DB61-02368A FUSE HOLDER ASS'Y 1
21 DB90-01539A ASS'Y BRACKET MOTOR ASS'Y 1
22 DB90-01589B ASS'Y CABINET BACK-RH ASS'Y 1
23 DB93-03828C ASS'Y MAIN PCB ASS'Y 1
DB93-03828D ASS'Y MAIN PCB ASS'Y -
24 DB97-02613A ASS'Y BRACKET-VALVE ASS'Y -
DB90-02434A ASS'Y BRACKET-VALVE ASS'Y 1
25 DB61-01857A BRACKET WIRE SECC-P,T1.0 1
26 DB64-01231A HANDLE SC-90073R 3
27 DB99-00618C ASS'Y LIQUID BYPASS V/V ASS'Y 1
28 DB99-00619B ASS'Y HOT GAS V/V ASS'Y 1
29 DB95-00564C ASS'Y HEATER COMP ASS'Y 1
30 DB99-00747A ASS'Y PWM VALVE ASS'Y 1
31 DB63-00691A GUARD FAN ASS'Y 2
32 DB96-04538B ASS'Y TUBE RECEIVER ASS'Y 1
33 DB96-05678A ASS'Y TUBE SUCTION ASS'Y 1
SA
SNA
SA
SA
SNA
SA
SA
SA
SA
SNA
SNA
SNA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SNA
SA
SA
SNA
SNA
SNA
SA
SA
SA
SA
SA
SA
SA
SA
1
1
1
1
1
1
1
1
1
-
1
1
1
-
1
1
1
-
1
-
1
1
1
1
1
1
2
1
1
1
-
1
1
-
1
3
1
1
1
1
2
1
1
RVXMHF050G
✳
RVXMHF060G
✳
