4-8Samsung Electronics
Disassembly and Reassembly
No Parts Procedure Remark
6 Ass'y Evap
1) Disassemble the screws of Ass'y Evap
around.
2) Disassemble indicating screws as
shown in picture and separate Ass'y
Cabinet Side-LF B.
3) Separate Ass'y Evap pulling up from the
indoor unit as shown in picture.
