Disassembly and Reassembly
Samsung Electronics4-23
No Parts Procedure Remark
4 Ass'y Drain Pump
12) Loosen nuts to disassemble the Motor.
1) Loosen the bolts of the Drain Pump.
2) Disassemble the hose from the
Drain Pump.
3) Disassemble the pump from the
Indoor Unit Bracket.
