Samsung DVM Plus 2 Series User Manual

Disassembly and Reassembly
4-24Samsung Electronics
No Parts Procedure Remark
5 Ass'y Evap 1) Disassemble the cover pipe beside the
Indoor Unit.
2) Loosen the bolts fixing the Heat
Exchanger to the indoor unit Base.
3) Disassemble the fixing brackets of the
Heat Exchanger to disassemble it from
the Indoor Unit.
