3.DisassemblyandReassembly
DescriptionDescriptionPhoto
5.DisconnecttheDECKcablefromtheMAINPCB.
•Unfastenthescrewsof4pointsaroundDECKAssy.
:BH,+,-,B,M3,L8,ZPC(WHT),SWRCH18A
•RemovetheDECKAssyfromtheCoverBottom.
6.ForWi-Fi,unfasten1screwanddisconnectFFC.
:BH,+,-,B,M3,L8,ZPC(WHT),SWRCH18A,ROUNDTYPE
7.Unfasten5screwsonSMPSPCB.
:BH,+,-,B,M3,L6,ZPC(WHT),SWRCH18A,RF
Disconnecttheconnectorandthepowercord.
