3.DisassemblyandReassembly
DescriptionDescriptionPhoto
8.Disconnectthe20pinwireandthe2pinwire.
Unfasten4screwsonMainPCB
:BH,+,-,B,M3,L8,ZPC(WHT),SWRCH18A,ROUNDTYPE
9.Unfasten2screwsonRearSide.
:BH,+,B,M3,L10,ZPC(BLK),SWRCH18A
Unfasten2screwsonRearSideforFAN.
:BH,+,B,M3,L10,ZPC(BLK),SWRCH18A
10.Unfasten3screwsonUSBPCB.
:BH,+,-,B,M3,L8,ZPC(WHT),SWRCH18A,ROUNDTYPE
PullouttheASSY .
Disconnectthe20pinwire.
11.Unfasten1screwonUSBPCB.
:BH,+,B,M3,L10,ZPC(BLK),SWRCH18A
PushthehookandpullUSBPCB.
3-4Copyright©1995-2012SAMSUNG.Allrightsreserved.
