4.AlignmentandTroubleshooting
4.1.8.3.TechModeMenudescription
1)DataSetup
•StorageDeviceSetup(Formatmassstoragedevice)
Thismenucanformatthestoragedeviceinthemachine.
•CounterReset
ThismenucanresetthecountsfortheFuser,Pickuproller,Retardroller,orTransferroller.Whenreplacingtheseparts,
youmustdothismenu.
•TonerLowLevel
Whenthetonerremainslessthansettinguplevel,themachinenotifyuseroftonerlow.
•PaperSubstitution
BetweenA4andLettersizepaper,printjobcanbeexecutedwithoutpapermismatchmessage,whenthesetting
valueis“On”.
2)Report
•Conguration
ItshowsvariousSWversionandcurrentmachinesettingstatus.
•SuppliesInformation
Itshowsconsumableunitlifestatusandtonerusingstatus.
•UsageCounter
Itshowsprintingusagebypapersizeandtype.
•ErrorInformation
Itshowsvariouskindsoferrorswhichcanbeoccurredinmachine.Italsostorehistoryerrorcounthowmanyerrorsare
issued.
•JobDuty
Itshowsprintingusagebyprintjobduty.
3)EDCMode
•NVRAMRead/Write
Thismenucanchangeacongurationvalueforenginermware.
Display
Code
GUI4–LineLUI
MeaningDefaultMax/MinRemark
104-0000
PickuprollerLife
PageCounter
0000-PickRol
Life
PickuprollerLifePageCounter0100K/0
104-0020
RetardRollerLife
PageCounter
RetardRol
Life
RetardrollerLifePageCounter0100K
104-0021
T2RetardRoller
LifePageCounter
T2RetardRol
Life
T2RetardRollerLifePageCounter0100K
104-0022
T3RetardRoller
LifePageCounter
T3RetardRol
Life
T3RetardRollerLifePageCounter0100K
104-0023
T4RetardRoller
LifePageCounter
T4RetardRol
Life
T4RetardRollerLifePageCounter0100K
104-0024
T5RetardRoller
LifePageCounter
T5RetardRol
Life
T5RetardRollerLifePageCounter0100K
