Samsung ML-451 Series - 2.2.12.2. Electrical parts location

2.ProductSpecicationsandDescription
2.2.12.2.Electricalpartslocation
Thefollowingdiagramdisplaystheelectricalpartssuchassensorandmotor.
M
2
M1
M3
S 2
S 7
S 9
S 8
S 4
S 3
S 6
S 5
S 1
P 1
S 10
S 11
S 12
S10604-001095PISENSOR:GP1S73P2EntranceSensor
S20604-001095PISENSOR:GP1S73P2ExitSensor:Bin#1
S30604-001095PISENSOR:GP1S73P2FullSensor:Bin#1
S40604-001095PISENSOR:GP1S73P2ExitSensor:Bin#2
S50604-001095PISENSOR:GP1S73P2FullSensor:Bin#2
S60604-001095PISENSOR:GP1S73P2ExitSensor:Bin#3
S70604-001095PISENSOR:GP1S73P2FullSensor:Bin#3
S80604-001095PISENSOR:GP1S73P2ExitSensor:Bin#4
S90604-001095PISENSOR:GP1S73P2FullSensor:Bin#4
S100604-001095PISENSOR:GP1S73P2LowerGateSensor
S110604-001095PISENSOR:GP1S73P2UpperGateSensor
S12JC81-03469AMICROSWITCH:VP333A-0DDoorOpenSwitch
M1JC81-07280ASEPARA TEMOTOR:SUBASSYLowerGateMotor
M2JC81-07280ASEPARA TEMOTOR:SUBASSYLowerGateMotor
M3JC81-07281AHBMOTOR:FEED:SUBASSYFeedMotor
P1JC81-07277AAS-PCBASSYMAINMailboxPCB
Copyright©1995-2016SAMSUNG.Allrightsreserved.2-60
