Samsung ML-451 Series - System Layout

2.ProductSpecicationsandDescription
2.2.4.SystemLayout
1
10
11
3
2
12
4
5
6
14
7
8
9
13
1MailBoxorFinisher63rdTray(Optional)11ImagingUnit
2LaserScanningUnit74thTray(Optional)12TransferUnit
3FuserUnit85thTray(Optional)13MPTray
41stTray9Stand14Pick-Uprollers
52ndTray(Optional)10TonerCartridge
