2.ProductSpecicationsandDescription
2.2.10.5.EraserPBA
EraserPBAiscomprisedofmanyLEDcomponents.EachLEDisusedforerasingnegativechargesonthesurfaceofthe
drumafterprinting.
•Information
-SEC-CODE:JC92-02373A
-PBAName:Eraser
2.2.10.6.Cover-OpenPBA
ThisboardcutsoffandsupplyDCpowerwhenthefrontcoverisopenedorclosed.Ithasthe24Vpowerinterlock
functionforsafety.
•Information
•SEC-CODE:JC92-02371A
•PBAName:Cover-Open
•Connection
15VL
25V
3,4,524VS
6,7,824V
