3.DisassemblyandReassembly
3.2.Screwsusedintheprinter
Thescrewslistedinthetablebelowareusedinthisprinter.Pleaseensurethat,whenyoudisassembletheprinter,youkeep
anoteofwhichscrewisusedforwhichpartandthat,whenreassemblingtheprinter,thecorrectscrewsareusedinthe
appropriateplaces.
PartCodeLocationDescriptionQty
6002-000440CASSETTESCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWRCH18A11
6003-000196CASSETTESCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A4
6003-000269CASSETTESCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-3
6002-000440CASSETTE-SIDERIGHTSCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWRCH18A2
6003-000196FUSERSCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A3
6003-000261FUSERSCREW-TAPTYPE;BH,+,-,B,M3,L6,ZPC(WHT),SWRCH18A,-11
6003-000269FUSERSCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-25
6006-001193FUSERSCREW-MACHINE;PH,+,WSP ,M3,L10,ZPC(WHT),SWRCH18A,1
6003-000269FRAME-BASESCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-44
6003-000196EXITSCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A20
6009-001665DRIVEEXITSCREW-HEX;HWH,+,M3,L6,ZPC(WHT),SWRCH18A,CTYPE5
6003-000196DUPLEXSCREW-TAPTYPE;PWH,+,B,M3,L10,NIPL T,SWRCH18A3
6003-000269DUPLEXSCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-11
6009-001492DUPLEXSCREW-HEX;HWH,+,M3,L8,NIPLT,SWRCH18A,S,RF4
6001-000545
DUPLEX-FEEDER
LOWER
SCREW-MACHINE;PH,+,M3,L4,NIPLT,SWRCH18A,FP ,-2
6003-000196FRAME-LEFTSCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A3
6003-000269FRAME-LEFTSCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-9
6002-000440
FRAME-GUIDE
CASSETTELEFT
SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWRCH18A1
6003-000196
FRAME-TERMINAL
FUSER
SCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A1
6003-000196FRAME-RIGHTSCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A2
6003-000269FRAME-RIGHTSCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-18
6003-000196DRIVE-FEEDSCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A3
6003-000269DRIVE-FEEDSCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-4
6003-000196
FRAME-GUIDE
CASSETTERIGHT
SCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A1
6003-000196FRAME-UPPERSCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A2
6003-000196FRAME-MAINSCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A13
6003-000269FRAME-MAINSCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-37
6003-000269DRIVEMAINSCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-12
6003-000301DRIVEMAINSCREW-TAPTYPE;BH,+,S,M4,L6,ZPC(WHT),SWRCH18A8
6009-001665DRIVEMAINSCREW-HEX;HWH,+,M3,L6,ZPC(WHT),SWRCH18A,CTYPE7
6003-000196
FRAME-GUIDEOPC
RIGHT
SCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A2
6003-000196FRAME-MIDDLESCREW-TAPTYPE;PWH,+,B,M3,L10,NIPLT,SWRCH18A13
Copyright©1995-2016SAMSUNG.Allrightsreserved.3-3
