Samsung ML-451 Series - Cover-SMPS and SMPS; Drive Assy; Pick up and Duplex Clutch

3.DisassemblyandReassembly
3.4.13.4.Cover-SMPSandSMPS
1.Remove4screwsecuringCover-SMPS.2.Remove3screwsecuringSMPS.
3.4.13.5.DriveAssy
1.Don’tcompletelyreleaseDriveafterremovingthe
screw.MakeaonlyspaceforreleasingClutch.
3.4.13.6.PickupandDuplexClutch
1.Releasethecoverafterremovingthescrewsforeach
cover
