3.DisassemblyandReassembly
3.3.2.Pickup/Forwardroller
1.Removethecassette.2.Removethepickupandforwardrollerasshownimage.
2
1
3.3.3.Transferroller
1.Openthefrontcover.Removethetonercartridgeand
imagingunit.
2.Pushthebothhandlestothedirectionofarrow.Take
offthetransferroller.
1
1
2
