2.ProductSpecicationsandDescription
2.2.12.3.Mailboxmainboard
Thefollowingdiagramdisplaystheconnectioninformationofthemailboxmainboard.
P /J 5
P /J 4
P /J 3
P /J 2
P /J 1
ConnectorNumberName
P/J1PSU(+24V ,+5V),ENGINEINTERFACE
P/J2DoorSwitch
P/J3FeedingMotorandUpperGateMotors
P/J4Entrance,UpperGateSensors
P/J5Exit,FullSensors
2-61Copyright©1995-2016SAMSUNG.Allrightsreserved.
