3.DisassemblyandReassembly
3.4.12.CoverOpenPBA
1.Removetherightcoverandtopcover.2.ReleasetheCoverOpenPBAafterremoving2screws.
3.4.13.DisassemblingPickupassy
NOTE
BeforedisassemblingPickupassy,havetodisassemblethepartsonthefollowingbookmark3.3.13.1~3.3.13.8.
3.4.13.1.LeftCover
1.Remove2screwintherear.2.Remove3screwinthefront.
3.ReleaseLeftCoverafterremovingthescrews.
Copyright©1995-2016SAMSUNG.Allrightsreserved.3-15
