3.DisassemblyandReassembly
3.4.10.LSU(LaserScanningUnit)
1.Removethetopcover.
2.Taketheatcableoff.
3.Remove4screwsand2harness.ReleasetheLSU.
NOTE
WhenreassemblingtheLSU,positiontheharnesscenter
linetothearrowontheLSU.
3.4.11.EraserLampPBA
1.Removethetopcover.
2.RemovetheLSU.
3.Remove1screwandpush1hook.
4.PulltheeraserlampPBAtotheleftslightly.Andthen
releaseit.
1
2
3-14Copyright©1995-2016SAMSUNG.Allrightsreserved.
