Samsung ML-451 Series - 2.2.10.4. HVPS Board

2.ProductSpecicationsandDescription
2.2.10.4.HVPSBoard
HVPS(HighV oltagePowerSupply)Unitgenerateshigh-voltagechannelswhichincludesTHV ,MHV ,DEVEAC,DEVE
DC,Fuser-biasandSAW.
1
2
3
4
5
6
7
8
9
•Information
-SEC-CODE:JC44-00202A
-PBAName:HVPSMONO
•Connection
1DEV4SAW7RearFan
2MHV5FuserBias8NSENS
3THV6HVPSInput9LSUFan
