3.DisassemblyandReassembly
3.4.5.OPCandMainmotor
1.Removetherightcover.
2.UnplugtheconnectorontheOPCmotor.Remove4
screws,thenreleasetheOPCmotor.
3.UnplugtheconnectorontheMainmotor.Remove4
screws,thenreleasetheMainmotor.
OP C Mo to r
Main Mo to r
3.4.6.MainDriveunit
1.Removetherightcover.
2.RemovetheJointPBA.
3.RemovetheSMPScover.
4.RemovetheMPclutchandtheGear.
E-Ring
E-Clip
MP Clutc h
5.ReleasetheMaindriveunitafterremoving5screws.
1
2
3
4
5
NOTE
Whenreassemblingthemaindriveunit,tighten5screws
inorderasshownabove.
Copyright©1995-2016SAMSUNG.Allrightsreserved.3-11
