1. Overview 1-11
Inverter Overload
Motor coasts to stop in 1 minute at approx.
150% of inverter rated current.
Overvoltage Motor stops at 820V or higher.
Undervoltage Motor stops at 380V or lower.
Cooling Fin
Overheat
Motor stops if the temperature of the
cooling fin is higher than 90℃.
Momentary Power Loss
Motor stops if power loss is 15ms or longer,
by selecting the momentary power loss
mode, operation can be continued if power
is restored within 500ms.
Stall Prevention
Automatic setting during acceleration,
deceleration, and constant speed operation
(individual setting is possible).
Power Charge
Indication
LED is ON until the DC bus voltage
becomes 50V or less.
Location
Indoor
(Free from corrosive gas, dust, or oil)
Ambient Temperature -10 ~ 40℃
Humidity 90% RH or less
Storage Temperature -20 ~ 60℃
*3
Environmental
condition
Vibration
Normally 0.2G or less, less than 20Hz, 1G
max.
*1.
The maximum applicable motor capacity is for a standard 4-pole
motor. When selecting the motor and inverter, make sure that the
inverter’s rated current is applicable fro the motor’s rated current.
*2. Tuning may be required.
*3. The storage temperature refers to the temperature during the
transportation for a short period of time.
1-12 MOSCON-E7 User’s Manual
1.5 Short circuit rations
Suitable for use in a circuit capable of delivering not more than 5kA rms
symmetrical amperes.
1.6 Fuse
The fuse used on the input side should be any of the UL Class K5 fuses having
The ratings as listed below.
Model
Rated
Voltage(V)
Rated
Current(A)
Model Rated
Voltage(V)
Rated
Current(A)
20P4 10 40P4 16
20P7 10 40P7 16
21P5 20 41P5
500
16
22P2 20 42P2 20
23P7 30 43P7
600
20
20P4S 20
20P7S 20
21P5S 20
22P2S
250
30
