Samsung MOSCON-E7 - Table 1.3 Specifications for 400 V Class

1. Overview 1-9
Starting Torque 150%/3Hz
Motor Overload
Motor stops in 1 minute at approx. 150% of
motor rated current.
Instantaneous
Overcurrent
Motor stops immediately at 200% of inverter
rated current.
Inverter Overload
Motor coasts to stop in 1 minute at approx.
150% of inverter rated current.
Overvoltage Motor stops at 410V or higher.
Undervoltage Motor stops at 190V or lower.
Cooling Fin
Overheat
Motor stops if the temperature of the cooling
fin is higher than approximately 90℃.
Momentary Power Loss
Motor stops if power loss is 15ms or longer,
by selecting the momentary power loss mode,
operation can be continued if power is
restored within 500ms.
Stall Prevention
Automatic setting during acceleration,
deceleration, and constant speed operation
(Individual setting is possible).
Protective Functions
Power Charge
Indication
LED is ON until the DC bus voltage becomes
50V or less.
Location
Indoor
(Free from corrosive gas, dust, or oil)
Ambient Temperature -10 ~ 40℃
Humidity 90% RH or less
Storage Temperature -20 ~ 60℃
*3
Environmental
condition
Vibration
Normally 0.2G or less, less than 20Hz, 1G
max.
*1. The maximum applicable motor capacity is for a standard 4-pole
motor. When selecting the motor and inverter, make sure that the
Inverter’s rated current is applicable for the motor’s rated current.
*2. Tuning may be required.
*3.
The storage temperature refers to the temperature during the
transportation for a short period of time.
1-10 MOSCON-E7 User’s Manual
Table 1.3 Specifications for 400V class
SI- E7
3 phase
40P4 40P7 41P5 42P2 43P7
Max. Applicable
Motor Capacity[kW]
*1
0.4 0.7 1.5 2.2 3.7
Inverter Capacity[kVA] 1.4 2.6 3.7 4.2 6.5
Rated Output Current[A] 1.8 3.4 4.8 5.5 8.6
Rated Output Voltage[V]
3phase, 380~460Vac
(Proportional to input voltage)
Output
Max. Output Frequency
[Hz]
600Hz
Input Voltage
and Frequency
3 Phase, 380~460Vac, 50/60Hz
Rated Input Current[A] 2.4 4.7 7.0 8.1 12.0
Input
Allowable Fluctuation
Voltage: -15% ~ +10%,
Frequency: ±5%
Control Method Space vector PWM, VVVF method
Frequency Control Range 0.01 ~ 600Hz
*2
Frequency Accuracy
Digital : ±0.01% (-10 ~ 50℃)
*2
Analog : ±0.5% (25℃±10℃)
Frequency Setting
Resolution
Digital (operator): 0.01Hz
Analog: 0.06/60Hz (1/1,024:10-bit)
Output Frequency
Resolution
0.01Hz
Overload Capacity 150% of rated current for 1min
Frequency Setting Signal
DC0~10V(
Input impedence :20 ㏀)
DC4~20mA(
Input impedence :250Ω)
Accel/Decel Time
0.1~3000.0sec (unit of 0.1sec setting)
Includes 2-set each.
Continuous Regenerative
Torque
20% of rated torque
V/f Pattern 15 of fixed pattern and 1 of optional pattern
Control Characteristics
Starting Torque 150%/3Hz
Motor Overload
Protection
Motor stops in 1 minute at approx. 150% of
motor rated current.
Protective
Function
Instantaneous
Overcurrent
Motor stops immediately at 200% of inverter
rated current.
