5. Parameters 5-59
• Setting
Setting
constant
Function
0 Frequency is decreased/increased by 0.01Hz.
1 Frequency is decreased/increased by 0.05Hz
5.7.5.6 Setting the parameter setting mode : H4.06
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
H4.06
Parameter setting
mode
- 0~1 1 X
• H4.06 can be used to set the parameter setting method.
• Setting
Setting
constant
Function
0
Changes group/subgroup at the same time
(ex: Divides into ‘U0’ or ‘01’)
1
Changes group/subgroup individually
(ex: Divides into ‘U’, ‘0’ or ‘01’)
5.7.5.7 Setting the fan operating method : H4.07
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
H4.07
Fan Operation
Mode
- 0~1 1 X
• H4.07 can be used to set the fan operation method.
• Setting
Setting
constant
Function
0 Rotates continuously
1 Stops when the motor is stopped
5-60 MOSCON-E7 User’s Manual
5.8 P-Parameter : Protective functions
5.8.1 Motor overload protection
Motor overload protection function monitors temperature of the motor
based on the output current of the inverter in order to protect the motor
from overheating.
5.8.1.1 Select motor protection : P0.01
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
P0.01
Select Motor
Protection
- 0~1 1 X
• Setting
Setting
constant
Function
0 Disabled
1 Enabled
• P0.01 can be used to enable or disable the motor overload protection
function.
• The rated current setting (C2.03) is used as a basis for overload detection.
A motor may not be protected when the power supply is turned on
and off frequently, because the thermal value is reset each time the
power is turned off.
• When two or more motors are connected to a single inverter:
- Disable the motor protection function (setting 0)
- Use another method for overload protection to each motor
(e.g. connect to a thermal overload relay to the power line of each motor)
CAUTION
!
