5. Parameters 5-57
5.7.5 Digital operator setting
5.7.5.1 Setting the display format in U0.07 : H4.01
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
H4.01
Display Format
of U0.07
- 0~3999 30 O
• H4.01 is used to set the display format of U0.07.
Digit 3 Digit 2 Digit 1 Digit 0 Range
H4.01
Position of
Decimal Point
(0~3)
Number to be multiplied to
the frequency
0000~3999
5.7.5.2 Setting the STOP key enable/disable : H4.02
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
H4.02
Digital
Operator Stop
- 0~1 1 X
• H4.02 is used to enable or disable the stop key during operation using
input terminals.
• Setting
Setting
constant
Function
0
The stop key is disabled when the run command is input from
the external terminal.
1 The stop key is enabled at all times during operation.
5.7.5.3 Setting the operation when switching
REMOTEÆLOCAL : H4.03
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
H4.03
Operation
when Change
Local Remote
- 0~1 0 X
• H4.03 is used to set the interlock operation to be used after switching
REMOTEÆLOCAL.
5-58 MOSCON-E7 User’s Manual
• Setting
Setting
constant
Function
0
Operate according to the RUN signal after switching to local.
1
No operation even if the Run signal is on after switching to local
5.7.5.4 Setting the device ID : H4.04
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
H4.04 Device ID - 1~253 1 O
• H4.04 is used to set the number to identify the node address of the
inverter during communication.
• Setting
Setting
constant
Function
1
Representative receiver: perform and response to command to #1
and #255
2~253
Normal receiver: perform command to itself and #255, but
response only to command to itself.
254
Not selectable: entire inverters on network respond (remote
operation)
255
Not selectable: only representative inverter on network responds
(broadcast)
5.7.5.5 Select frequency unit : H4.05
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
H4.05
Select
Frequency Unit
of Digital
Volume
- 0~1 1 O
• H4.05 is used to set the frequency unit when using the digital volume.
