5. Parameters 5-5
Table 5.3 Inverter operation status on last fault
Name Unit Display
U1.01 Command Frequency 0.01Hz xx.xx~xxx.x
U1.02 Output Frequency 0.01Hz xx.xx~xxx.x
U1.03 Output Current 0.01A xx.xA
U1.04 Output Voltage 1V xxxu
U1.05 DC Voltage 1V dxxx
U1.06 Output Power 0.1kW Pxx.x
U1.07 Motor rpm 1rpm xxxx
U1.08 Output Torque 1% oxxx
U1.09 I/O Status bit
U1.10 Cumulative Power On Time 10Hr xxxx
Table 5.4 Fault list
Name Unit Display
U2.01 Fault 1 (recent one) - *
U2.02 Fault 2 - *
U2.03 Fault 3 - *
U2.04 Fault 4 - *
Table 5.5 Parameter Check list
Name Unit Display
U3.01 Modified Parameter List - “----” (None)
U3.02 Fault Parameter List - “----” (None)
• The commonly used drive operating conditions are monitored from
U0-group. All parameters except U0.01 in this group are read-only.
• Note that unless the source of frequency command is changed, the
data in U0.01 (frequency command) is not changed even though the
power is off.
5-6 MOSCON-E7 User’s Manual
• U3.01 and U3.02 have the function of list reference. Here, Up/Down
( , ) keys are used in shifting between the items internally. Also,
the number of next item is displayed.
Shift( ) key is used in shifting between the content and number of
the item.
