3.Wiring 3-7
3.3 Main circuit terminal functions
Table 3.1 200V class main circuit terminal functions
Purpose Symbol
Main circuit power input R/L1, S/L2, T/L3
Inverter outputs U/T1, V/T2, W/T3
DC power input +1, N
DC reactor connection +1, +2 (Remove short-bar)*
Braking unit connection P/B, N (No internal braking unit)
Auxiliary capacitor (+): P/B (-):N
Ground
*Short-bar must be removed when connecting the DC reactor.
Table 3.2 400V class main circuit terminal functions
Purpose Terminal Symbol
Main circuit power input R/L1, S/L2, T/L3
Inverter output U/T1, V/T2, W/T3
DC power input
+2, N (Additional circuit is needed to
prevent the damage caused by inrush
current.)
DC reactor connection +1, +2(Remove short-bar)*
Braking resistor unit
+2, P/B (used for the internal braking
unit)
Braking unit +2, N
Auxiliary capacitor (+) : +2 (-) : N
Ground
*Short-bar must be removed when connecting the DC reactor.
3-8 MOSCON-E7 User’s Manual
3.4 Control circuit terminal functions
Table 3.3 Control circuit terminal block
Ter minal Function Signal level Default setting
1 Forward run/stop command -
2 Reverse run/stop command -
3 Multi-function input 1 External fault
4 Multi-function input 2 Fault reset
5 Multi-function input 3 Multi-step speed1 command
6 Multi-function input 4
Photo-Coupler input
+24V, 10mA
Jogging command
7
Sequence control input
common
+24V Ground Sequence 0V
8 Power for freq. command +12V(Max 20mA) -
9
Voltage command for output
frequency
DC 0～+10V(25Ω) -
10
Current command for
output frequency
4～20mA(250Ω) -
11 Analog monitor output 0V -
12 Common for control DC 0 ～ +10V (Output frequency)
A1
B1
C1
Multi-function output
Contact :
AC 250V, 1A or below
DC 30V, 1A or below
Fault occurred
Note) Be attentive to below mention when changing output frequency in using the
external frequency command terminal.
- Voltage command input terminal is set only in factory setting.
- Change setting value of parameter H2.01 from 0 to 1 in using the current
command input terminal.
- In setting the function of contact input, H0.02~H0.05, parameter H2.01
is regardless if voltage current command transfer(14) is set.
