Samsung MOSCON-E7 - Multi-Function Analog Input; Motor Protection

Appendix
A
-9
Multi-Function Output
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
H1.01
Select Terminal
Output Type
- 0~1 0 X 5-50
H1.02
Function of
Output Terminal
- 1~11 0 X 5-50
Multi-Function Analog Input
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
H2.01 Analog Input Type - 0~3 0 X 5-52
H2.02
Analog Input
Time Constant
1ms 0~100 20 X 5-52
H2.03
V
oltage Input Gain
(Terminal 9)
0.1% 0.0~200.0 100.0 ○ 5-53
H2.04
Voltage Input Bias
(Terminal 9)
0.1% -100~100 0.0 ○ 5-53
H2.05
Function of
Current
Input Terminal
- 0~7 0 X 5-54
H2.06
Current
Input Gain
(Terminal 10)
0.1% 0.0~200.0 100.0 ○ 5-53
H2.07
Current
Input Bias
(Terminal 10)
0.1% -100~100 0.0 ○ 5-53
Multi-Function Analog Monitor Output Terminal
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
H3.01
Analog Monitor
Function Setting
- 0~7 1 X 5-55
H3.02
Analog Monitor
Gain Setting
0.1% 0.0~200.0 100 ○ 5-56
H3.03
Analog Monitor
Bias Setting
0.1% -100~100 0.0 ○ 5-56
A-10 MOSCON-E7 User’s Manual
Digital Operator Setting
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
H4.01
M
otor Speed Form - 0~3999 30 ○ 5-57
H4.02
Digital
Operator Stop
- 0~1 1 X 5-57
H4.03
Operation when
Change Local
Remote
- 0~1 0 X 5-57
H4.04 Device ID - 1~253 1 ○ 5-58
H4.05
Select
Frequency Unit of
Digital Volume
- 0~1 1 ○ 5-58
H4.06
Parameter Setting
Method
- 0~1 1 X 5-59
H4.07
Fan Operation
Mode
- 0~1 1 X 5-59
P-parameter
Motor Protection
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
P0.01
Select
Motor Protection
- 0~1 1 X 5-60
P0.02
Motor Protection
Time Constants
min 0.0~60.0 8.0 X 5-61
P0.03 Motor Selection - 0~1 0 X 5-62
Momentary Power Failure
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
P1.01
Operation at
Power Loss
- 0~2 1 X 5-63
P1.02
Compensation
Time of Power
Loss
0.1sec 0.0~2.0 0.5 X 5-63
P1.03
V/f Recovery
Time
0.1sec 0.0~2.0 0.5 X 5-64
P1.04
Undervoltage
Level
1V 0~250 190 X 5-64
