Appendix
A
-7
C-parameter
V/f Setting
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
C0.01 V/f Pattern - 0~15 15 X 5-31
C0.02
Max Output
Frequency
0.01Hz 30.00~600.00 60.00 X 5-37
C0.03
Max Output
Voltage
0.1V 0.0~250.0 200.0 X 5-37
C0.04 Base Frequency 0.01Hz 30.00~600.00 60.00 X 5-37
C0.05
Mid Output
Frequency
0.01Hz 0.00~600.00 3.00 X 5-37
C0.06
Mid Output
Voltage
0.1V 0.0~250.0 14.0 X 5-37
C0.07
Min Output
Frequency
0.01Hz 0.00~600.00 1.50 X 5-37
C0.08
Min Output
Voltage
0.1V 0.00~250.0 8.0 X 5-37
Carrier Frequency/ Modulation Related Setting
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
C1.01 Carrier Frequency 0.01Hz 1.50~10.00 10.00 X 5-38
Motor Data
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
C2.01 Stator Resistance 0.01Ω 0.00~99.99 * X 5-38
C2.02 Iron Loss 1W 0~9999 * X 5-38
C2.03
Rated Output
Current
0.1A 0.0~999.9 * X 5-39
C2.04
No Load
Current
0.1A 0.0~999.9 * X 5-39
C2.05 Rated Slip 0.01Hz 0.00~600.0 * X 5-39
A-8 MOSCON-E7 User’s Manual
H/W Adjusting Data
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
C3.01
DC Voltage
Compensation
- - * X 5-40
C3.02
Analog Output
Compensation
Coefficient
- - * X 5-40
C3.03
Current Detector
Compensation 1
- - * X 5-40
C3.04
Current Detector
Compensation 2
- - * X 5-40
C3.05
Analog Command
Compensation
Coefficient
- - * X 5-40
C3.06
Current Terminal
Gain
Compensation
Coefficient
- - * X 5-40
C3.07
Current Detector
Compensation
Coefficient
- - * X 5-40
H-parameter
Multi-Function Inputs
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
H0.01
Select Terminal
Input Type
-
00~3F
(Hexa
-Decimal)
00 X 5-41
H0.02
Function of
Terminal 3
- 0~19 1 X 5-41
H0.03
Function of
Terminal 4
- 0~19 2 X 5-41
H0.04
Function of
Terminal 5
- 0~19 3 X 5-41
H0.05
Function of
Terminal 6
- 0~19 4 X 5-41
