5. Parameters 5-13
• If B0.07 is set as 1 the motor starts automatically at power-up.
It may cause a serious accident. Thus, pay extra caution when
using automatic start operation.
5.3.2 System initialization
5.3.2.1 Controlling the inverter initialization : B1.01
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
B1.01
Inverter
initialization
- 0~9999 0000 X
• B1.01 is used to initialize the parameters of the inverter .
When the inverter is initialized, all the changed parameters are deleted
and initialized to factory-setting values.
• Setting
Setting
constant
Function
1010 Complete initialization
1111 Partial initialization (exclude multi-functional I/O terminal setting)
DANGER
!
5-14 MOSCON-E7 User’s Manual
5.3.2.2 Setting and verifying the password : B1.02, B1.03
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
B1.02 Check password - 0~9999 0000 X
B1.03 Set password - 0~9999 0000 X
• B1.02 is used to check and verify the password when a password has
been set in B1.03(i.e. B1.03 ≠ 0000).
• B1.03 is used to set the new password.
• When the new password is entered and saved in B1.03, not blinking
0000 is displayed immediately regardless of the input password.
5.3.3 Setting power capacity
5.3.3.1 Setting the inverter and motor capacity : B2.01, B2.02
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
B2.01
Power capacity of
the inverter
-
20P4
~43P7
- X
B2.02
Power capacity
of the motor
-
20P4
~43P7
- X
• Parameter B2.01 is used to set the power capacity of the inverter.
• Parameter B2.02 is used to set the power capacity of the motor.
Capacity
(Motor &
Inverter)
0.4kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW
200V 20P4 20P7 21P5 22P2 23P7
400V 40P4 40P7 41P5 42P2 43P7
• The power capacity of the motor can not be set bigger than the
power capacity of the inverter.
• B2.01 and B2.02 can not be set to different voltage class.
NOTE
