Samsung MOSCON-E7 - 5.6.3.3 Setting the motor rated current: C2.03; 5.6.3.4 Motor no-load current: C2.04; 5.6.3.5 Setting the motor rated slip: C2.05

5. Parameters 5-39
5.6.3.3 Setting the motor rated current : C2.03
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
C2.03
Rated Output
Current
0.1A
0.0
~999.9
* X
• C2.03 is used to set the rated current (A) shown on the motor
nameplate.
• Default value depends on the inverter capacity.
5.6.3.4 Motor no-load current : C2.04
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
C2.04
No Load
Current
0.1A
0.0
~999.9
* X
• C2.04 is used as a reference value for the torque compensation.
• Default value depends on the inverter capacity.
• If rated voltage and rated frequency are not printed on the motor
nameplate, contact the motor manufacturer.
5.6.3.5 Setting the motor rated slip : C2.05
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
C2.05 Rated Slip 0.01Hz
0.00
~600.0
* X
• C2.05 is used as a reference value for the torque compensation.
• Default value depends on the inverter capacity.
• Calculate C2.05 from the value printed on the motor nameplate:
Rated slip=rated frequency(Hz) - rated speed(r/min) × number of
poles/120
5-40 MOSCON-E7 User’s Manual
5.6.4 H/W Adjusting data : C3.01~C3.06
Parameter
No.
Name Unit
Setting
range
Factory
Setting
Changeable
during
operation
C3.01
DC Voltage
Compensation
- - * X
C3.02
Analog Output
Compensation
Coefficient
- - * X
C3.03
Current Detector
Compensation
Coefficient 1
- - * X
C3.04
Current Detector
Compensation
Coefficient 2
- - * X
C3.05
Analog Command
Compensation
Coefficient
- - * X
C3.06
Current Terminal
Gain Compensatio
n
Coefficient
- - * X
C3.07
Current Detector
Compensation
Coefficient
- - * X
• C3.01~C.07 are set from the factory and the user is not allowed to
change the setting. (Modification may influence to system
performance)
CAUTION
!
