6. Specification
1) Dynamic brake and braking resistor
Inverter (CLASS 200V) Braking resistor (unit)
Capacity HP (kW) Specification (1 SET) Quantity (SET)
Braking torque
(10%ED)
0.5(0.4) 70W, 200Ω 1 220%
1(0.75) 70W, 200Ω 1 125%
2(1.5) 260W, 100Ω 1 125%
3(2.2) 260W, 70Ω 1 120%
5(3.7) 390W, 40Ω 1 125%
2) Specifications of dynamic brake
Model name / Specification SIBR-23P7 / 0.4~3.7kW 200V
Motor capacity kW (HP) 3.7 (5)
Max. discharge peak current (A) 10
Rated discharge current (A) 4
Braking starting voltage 330/345/365/380V± 3V
Output
characteristic
Max. hysteresis voltage error Approximately 8V
Power VDC 243~400V
Protection Overcurrent protection Protects overcurrent fuse
BRAKE
Turns on when braking
(Yellow LED).
LED
FAULT
Turns on when there is a fault
(Red LED)
Installation site
Indoor installation to protect form
corrosive gases and dust.
Ambient temperature
+14 ~ +104℉ or –10 ~ +40℃ (no
dew formation)
Storage temperature +4 ~ +140℉ or –20 ~ +60℃
Humidity 90% RH
Installation
condition
Vibration 1G (10 ~ 20Hz), 0.2G (20 ~ 50Hz)
Protective structure Closed-type panel
A-16 MOSCON-E7 User’s Manual
