OfficeServ 7400 INSTALLATION
TECHNICAL MANUAL PART 3 MAY 2010
3.18
TEPRI Card Dip Switch
Switch No. ON OFF
1 T1 E1
2 PRI T1
3 NFAS (24B) NFAS (23B + D)
4 NETWORK* USER
5 AFT NORMAL
6 ** **
7 ** **
8 ** **
*If this TEPRI/TEPRIa card is to be the master of a pair of TEPRI/TEPRIa cards that are used to
connect two systems together via PRI networking, DIP switch 4 must be set to ON.
**Do not change the settings of DIP switches 3, 5, 6, 7, and 8. Switches 3, 5, 6, and 7 must
remain OFF and 8 must be ON.
**The new TEPRIa and TEPRI2 cards have only a four-position switch. Set the switches the
same as the eight-position using the same first four switches.
See the S1 switch and jumpers of the TEPRI board as shown on the next page.
