Samsung SCX-6322DN Service Manual

΁ΒΣΥΤͽΚΤΥ
Drawer# Description SEC_Code QT'y Service
8.1-0 22 PPM FLATBED MFP SCX-6322DN/XAZ
8.1-1-1 ELA HOU-SCANNER JC96-04180X 1SA
8.1-2 MEA UNIT-COVER PA EX JC97-01556C 1 SA
8.1-2-1 PMO-TRAY EXT MP NE JC72-00354D 1 SA
8.1-2-2 PMO-COVER PAPER EXIT JC72-00786C 1 SA
8.1-3 MEA UNIT-CASSETTE JC97-01736D 1 SA
8.1-4 MEA UNIT-COVER FRONT JC97-01572C 1 SA
8.1-5 UNIT-LSU,600DPI,22 JC59-00014C 1 SA
8.1-6 ELA HOU-SHIELD SMPS JC96-04178A 1 SA
8.1-7 PBA SUB-LIU JC92-01793D 1 SA
8.1-8 SUPPORTER 6103-000101 2 SNA
8.1-9 ELA HOU-PICK UP PLUS JC96-02715C 1 SA
8.1-10 ELA HOU-SIDE COVER JC96-02183D 1 SA
8.1-11 ELA HOU-MP JC96-02182B 1 SA
8.1-12 ELA HOU-BASE FRAME JC96-04010C 1 SA
8.1-13 MEA UNIT-FEED ROLLER JC97-01850A 1 SA
8.1-14 ELA HOU-FUSER E_COIL JC96-03021C 1 SA
8.1-15 ELA HOU-FRAME MAIN JC96-04012A 1 SA
8.1-16 MEA UNIT-EXIT JC97-01643D 1 SA
8.1-17 ELA HOU-ENGINE DRIVE JC96-04183A 1 SA
8.1-18 MEA UNIT-REAR COVER JC97-01851D 1 SA
8.1-18-1 COVER-MAIN REAR DUMMY JC63-00192C 1 SA
8.1-18-2 COVER-MAIN REAR JC63-00191B 1 SA
8.1-19 PBA MAIN-CONTROLLER JC92-01792D 1 SA
8.1-20 COVER-PANNEL MFP JC63-01089C 1 SNA
8.1-21 ELA HOU-DUCT FAN JC96-02311A 1 SA
8.1-21-1 FAN-DC JC31-00012A 1 SA
8.1-21-2 PMO-DUCT FAN JC72-00807A 1 SA
8.1-24 SOLENOID-PICK UP JC33-00007A 1 SA
8.1-25 PMO-COVER EXIT REAR JC72-00790B 1 SA
8.1-26 MEA UNIT-GUIDE CST PA JC97-01624B 1 SA
8.1-26-1 PPR-SHEET/GUIDE PAPER JC72-00836A 1 SA
8.1-26-2 PMO-GUIDE CST RAIL JC72-00791B 1 SA
8.1-26-3 SHEET-FEED JC63-00078A 2 SNA
8.1-26-4 IPR-GUIDE CASSETTE PAPER JC70-00244A 1 SA
8.1-28 PMO-DUMMY BASE FRAME JC72-00789B 1 SA
8.1-29 ELA HOU-SHIELD MAIN JC96-04182A 1 SA
8.1-29-1 SHIELD-P_MAIN BOARD JC63-01092A 1 SNA
8.1-29-2 HARNESS-INLET JC39-00604A 1 SA
8.1-29-3 CBF HARNESS-LIU GND JB39-00103A 1 SA
8.1-30 PMO-COVER FEED AY JC72-00801A 1 SA
8.1-32 PMO-GUIDE PAPER OUT JC72-00835B 1 SA
8.1-33 SHEET-CONNECTOR JC63-00072A 1 SA
8.1-34 CBF HARNESS-LSU JC39-00336A 1 SA
8.1-35 HARNESS-HVPS JC39-00590A 1 SA
8.1-37 HARNESS-MAIN_MOTOR JC39-00598B 1 SA
8.1-38 GEAR-PICK_UP JC66-00335A 1 SA
8.1-39 IPR-SHIELD SMPS UPPER JC70-00248A 1 SA
8.1-40 MEA UNIT-HOLD GND ASS'Y JC97-01574A 1 SA
8.1-40-1 SPRING ETC-PLATE TR JC61-70203A 1 SA
8.1-40-2 SPRING ETC-TR_L JC61-70961A 1 SA
Service(SA:service available, SNA:service not avaialble)
Service Parts List(SCX-6322DN/XAZ)

