Samsung SCX-6322DN Service Manual

΁ΒΣΥΤͽΚΤΥ
Drawer# Description SEC_Code QT'y Service
Service(SA:service available, SNA:service not avaialble)
8.1-40-3 PMO-BUSH JC72-40228A 1 SA
8.1-40-4 PMO-HOLDER GND TR JC72-00883A 1 SA
8.1-41 MEA UNIT-HOLD GEAR ASS'Y JC97-01573A 1 SA
8.1-41-1 SPRING ETC-TR_R JC61-70906A 1 SA
8.1-41-2 PMO-BUSH JC72-40228A 1 SA
8.1-41-3 PMO-HOLDER GEAR TR JC72-00884A 1 SA
8.1-44 PMO-CAM JAM REMOVE JC72-00799A 1 SA
8.1-45 PMO-LOCKER DEVE JC72-00805A 1 SA
8.1-46 PMO-LEVER JAM REMOVE JC72-00804A 1 SA
8.1-47 HARNESS-POWER_SWITCH JC39-00601C 1 SA
8.1-48 GEAR-TRANSFER JC66-40947A 1 SA
8.1-49 PMO-BEARING SHAFT JC72-41191A 1 SA
8.1-50 MEC-TRANSFER ROLLER JC75-00148A 1 SA
8.1-51 PMO-COVER BRKT MOTER JC72-00834A 1 SA
8.2-0 ELA HOU-SCANNER JC96-04180X 1SA
8.2-1 ELA HOU-DADF JC96-02943B 1 SNA
8.2-2 ELA HOU-OPE JC96-04170X 1 SNA
8.2-3 ELA HOU-PLATEN JC96-04171A 1 SNA
8.3-0 ELA HOU-OPE JC96-04170X 1 SNA
8.3-1 COVER-DUMMY JC63-01155N 1 SNA
8.3-2 COVER-OPE JC63-01156X 1 SA
8.3-3 KEY-M_STOP CLEAR JC64-00242A 1 SNA
8.3-4 KEY-M_START BLACK JC64-00243A 1 SNA
8.3-5 KEY-M_TEL JC64-00239A 1 SNA
8.3-7 KEY-M_FAX JC64-00241A 2 SNA
8.3-8 KEY-M_ON HOOK JC64-00249A 1 SNA
8.3-9 KEY-M_MENU JC64-00248A 1 SNA
8.3-10 LENS-STATUS JC67-00198A 1 SNA
8.3-11 RUBBER-TEL JC73-00246A 1 SA
8.3-12 RUBBER-MODE JC73-00247A 1 SA
8.3-13 RUBBER-MENU JC73-00230A 1 SNA
8.3-14 COVER-LCD JC63-01157A 1 SNA
8.3-15 KEY-M_MODE SCAN JC64-00247A 1 SNA
8.3-16 KEY-M_MODE COPY JC64-00245A 1 SNA
8.3-17 KEY-M_MODE FAX JC64-00246A 1 SNA
8.3-18 RUBBER-FAX JC73-00248A 1 SA
8.3-19 RUBBER-EMAIL JC73-00245A 1 SA
8.3-20 ELA UNIT-OPE JC96-03994C 1 SA
8.3-21 PBA SUB-QWERTY JC92-01791D 1 SA
8.3-23 SCREW-TAPTITE 6003-000154 17 SA
8.4-33 ELA HOU-SCAN UPPER JC96-04034B 1 SA
8.4-33-1 PMO-COVER SCAN UPPER JC72-00758B 1 SA
8.4-33-2 MEA UNIT-DUMMY UPPER JC97-02800A 1 SA
8.4-33-2-1 PMO-DUMMY UPPER JC72-00759D 1 SA
8.4-33-2-2 MCT-GLASS ADF JC74-00019A 1 SA
8.4-33-2-4 SHEET-DUMMY UPPER JC63-00074A 1 SA
8.4-33-3 SHEET ABS-REGI_EDGE JC72-00809B 1 SA
8.4-33-4 SCREW-TAPTITE 6003-000154 2 SA
8.4-33-5 TAPE ETC-DOUBLE TAPE SMALL JC02-00013A 3 SNA
8.4-33-6 TAPE ETC-DOUBLE TAPE LARGE JC02-00012A 2 SNA
8.4-33-7 MCT-GLASS SCANNER(LEGAL) JC74-00018A 1 SA
8.4-33-10 IPR-HOLDER GLASS JB70-00148A 3 SA
8.4-34 ELA HOU-SCAN LOWER JC96-04172A 1 SNA
8.4-34-1 COVER-SCAN LOWER JC63-00157B 1 SNA
8.4-34-2 PMO-COVER DUMMY LOWER JC72-00753B 1 SA
8.4-34-3 SCREW-TAPTITE 6003-000154 15 SA

