TEMI 880
11.Program Set Screen
Click on the “PROG. SET” button in Figure 11 to enter Program Set screen as
Figure 47.
Program Set Screen
Figure 47
1 Name: click on the name column using alphabet keyboard edit program name.
2 Add: click on it to add up a new program.
3 SEG. NUM: setting each program’s segment value. See 11.1 Segment Edit
4 Cycle: setting the program or segment cycle. See 11.2 Loop Set
5 Other: other set of program. See 11.3 Other
► TEMI 880 with 120 group programs and each program has 100 segments.
► If segment value is equaled initial value, you are not able to insert or delete. On
the other hand, it is not able to insert or delete segment at the running status.
