TEMI 880
11.1.2. TS Set
Select a Time Signal in Figure 48 to setting its operation as Figure 51.
TS Set Screen
Figure 51
1 NO: totally 8 actions. OFF means always OFF, ON means always ON. AC1-
AT6 need to set its value by user.
2 Delay: setting delay time to delay turn on the time signal action.
3 ON time: setting wait time for the time signal output.
4 OFF time: setting running time for time signal output.
5 Cycle: setting the time signal cycle.
