OPERA
CAP. 2
Technical Data - Transportation - Unpacking
EN
2.1 - DIMENSIONS
2.2 - TECHNICAL DATA
A
B
C
2 UNITS 3 UNITS
A
745 mm 1040 mm
B
654 mm 654 mm
C
440 mm 440 mm
Units 2 UNITS 3 UNITS
Boiler capacity litres 8
Pre-heating boiler capacity litres 2.8
Independent unit capacity litres 0.5
Power supply voltage V 220-240 1N~
380-415 3N~
Boiler heating element absorbed power (230V) kW 3.85
Coffee heating element absorbed power (230V) kW 1.65
Independent unit heating element absorbed power kW 0.96
Cup heating plate heating element absorbed
power
kW 0.25
Total absorbed power kW 3,5 - 5,7 - 6,5 - 7,7 3,5 - 5,7 - 6,5 - 7,7
- 8,75
Boiler operating pressure Bar
(MPa)
0,8 ÷ 1,5 / 0,08 ÷ 0,15
Mains water pressure Bar
(MPa)
6 (0,6)
Coffee adjustment pressure Bar
(MPa)
8-12 (0.8-1.2)
Operating temperature °C 5 ÷ 35
