Sanremo Opera - Commissioning; A - First Start-Up

06-2017
CAP. 4
9 / 12
OPERA
Installation and connection
EN
MAX
°F
°C
MIN
124
8
3
2
1
4
9
7
8
2
7
3
A
MAX
°F
°F
°C
MIN
124
085
3
A
5
2
6
Fig. 8
4.6 - COMMISSIONING
4.6.a - First start-up (Fig. 8 - 9)
• Open the water supply tap upstream of the machine.
• Power on the machine power supply bringing the
breaker upstream of the machine to ON.
• Press the “ON/OFF” button (1) which turns on to
indicate that the machine is live; the unit displays
(2) turn on.
• Theboilerisautomaticallylledwithwater;thegrad-
ed scale “A” on the level display (3) turns on; when
the full level is reached, scale “A” is complete and
the display turns on fully.
• When the “MAX” level is reached, the graded scale
“A” stays o steady and the display is fully lit.
IMPORTANT
If automatic lling does not take place
within 120 seconds, the machine stops
and the LEDs on the unit button panels
light up and ash.
Check that the water supply tap is open.
• Whenllingiscompleted,dispensewaterfromthe
unitsbyoperatingonlevers(4),withoutttingthe
lterholders.
• Check that water comes out properly, venting any
air bubble present in the circuit.
IMPORTANT
Remove the cup heating plate (5) and
press button (6) for 3 or 4 seconds to fully
vent any air bubble in the circuit.
• Turn the steam dispensing levers (7) to open position
until steam is dispensed from the taps (8), then bring
the levers (7) back to the middle position.
• Dispense water by pressing button (9) located above
the unit to vent any air bubble in the circuit.
• Wait for the set temperature to be reached for steam
(“124°C”) and coffee water (“94°C”), which are shown
on display (3) and (2) of each dispensing unit, re-
spectively.
2 Units 3 Units
