Sanremo Opera - Machine Positioning

06-2017
CAP. 4
3 / 12
OPERA
Installation and connection
EN
Fig. 2
1
2
10 cm
10 cm10 cm
3
4.2 - MACHINE POSITIONING (Fig. 2)
ATTENTION
The coffee machine must be installed at a
safety distance of at least 10cm from the
side and rear walls.
HAZARD
The coffee machine cannot be installed in
areas where water jets are used.
IMPORTANT
The working surface must be sized so that
it can support the weight of the machine;
furthermore, the surface must be horizon-
tal and its height must be such that the top
part of the machine (cup heating plate) is
higher than 150 cm from the oor.
If necessary, drill two holes on the working
surface to let through the intake and drain
pipes and the power cable.
• Set aside some space for a used coffee container (1)
and a grinder/dosing machine (2) near the machine.
• Liftthemachineandpositionitinitsnallocation.
• If necessary, it can be levelled by means of the feet
(3).
