06-2017
2 / 12
OPERA
CAP. 4
Installation and connection
EN
Fig. 1
HAZARD
All operations described in this chapter
must be performed by a specialised and
authorised technician.
4.1 - LIFTING THE MACHINE (Fig. 1)
The machine must be lifted by four or more people
located on opposite sides of the machine, lifting it
manually while holding it from under the machine frame
base/support feet.
The machine can also be lifted by a hoist, inserting
the straps under the machine base and the other end
to a beam, so that external panels are not crushed.
ATTENTION
Do not use steel ropes for lifting, since
they may damage the external body.
